For High Volume Fluid Transfer & Spray Applications
Manufacturer: Binks
Part Number: PX1304
Description: PX1304 Pogo Pumps
Pogo Plus series, two-ball, double acting piston pumps are designed for the application and transfer of low-medium viscosity fluids. Models are available in Stainless Steel with either PTFE or UHMWE
packings and are compatible with a wide variety of materials including water or solvent borne paints and adhesives and most solvents. Pogo Plus pumps have a 4:1 ratio and are available with maximum pressure ratings of 290 psi or 500 psi.
-
Patented Air Motor Design
—Utilize AX55 air motor to provide quick changeover and reduced pulsation
-
Durable Pump Design
—Reduces maintenance cost -
Pump Outfit Available with Trophy Gun
—Trophy guns available with a new lightweight and ergonomic design -
5 Year Limited Warranty
—The finishing industry’s best warranty
APPLICATIONS
-
Furniture and Wood Cabinets
-
Truck and Bus
-
Adhesive Applications
-
Coating Supply
-
Solvent Supply for 2K Equipment
-
General Industry
Pump Performance
|
|
PX1304-5U |
PX1304-5P |
PX1304-8U |
PX1304-8P |
|
Pressure Ratio: |
4:1 |
4:1 |
4:1 |
4:1 |
|
Air Inlet Pressure: |
0–72.5PSI (5) |
0–72.5PSI (5) |
0–116 PSI (8) |
0–116 PSI (8) |
|
Fluid Pressure: |
0–290 PSI (20) |
0–290 PSI (20) |
0–500 PSI (34) |
0–500 PSI (34) |
|
Cycles Per Gallon: |
47 |
47 |
47 |
47 |
|
Displacement Per Cycle: |
2.7 (81cc) |
2.7 (81cc) |
2.7 (81cc) |
2.7 (81cc) |
|
Flow @60 Cycles/Min: Maximum recommended continuous cycle rate: Maximum recommended intermittent cycle rate: Maximum Operating Temperature: Piston diameter: Nominal motor stroke: Air Inlet Connection: Outlet Size: Weight: |
1.3 Gal (4.91 l/m) 20 cycles/min. [40 strokes]
40 cycles/min. [60 strokes]
160°F [71° C]
3.3 in (85 mm) 3 in [75 mm]
3/8" NPS/BSPP (female) 1/2" NPT(F) 12.6 Lb [5.7 Kg] |
1.3 Gal (4.91 l/m) 20 cycles/min. [40 strokes]
40 cycles/min. [60 strokes]
160°F [71° C]
3.3 in (85 mm) 3 in [75 mm]
3/8" NPS/BSPP (female) 1/2" NPT (F) 12.6 Lb [5.7 Kg] |
1.3 Gal (4.91 l/m) 20 cycles/min. [40 strokes]
40 cycles/min. [60 strokes]
160°F [71° C]
3.3 in (85 mm) 3 in [75 mm]
3/8" NPS/BSPP (female) 1/2" NPT (F) 12.6 Lb [5.7 Kg] |
1.3 Gal (4.91 l/m) 20 cycles/min. [40 strokes]
40 cycles/min. [60 strokes]
160°F [71° C]
3.3 in (85 mm) 3 in [75 mm]
3/8" NPS/BSPP (female) 1/2" NPT (F) 12.6 Lb [5.7 Kg] |
|
Packing Material: |
UHMW |
PTFE |
UHMW |
PTFE |
Spray Finishing Outfits
|
|
||
|
Pump: |
PX13045U |
PX13045U |
|
Gun: |
||
|
Air Control: |
||
|
Air Hose 25 Foot: |
||
|
Fluid Hose 25 Foot: |
||
|
Drum Bung Adapter: |
| Ref. No. | Part No. | Description | Qty |
| 1 | 0114-014351 | HANDLE | 1 |
| 2 | 0115-010272 | RETAINING RING | 2 |
| 3 | 0115-010001 | SOCKET HEAD CAP SCREW | 3 |
| 4 |
AX55S AIR MOTOR (8 BAR) AX55S AIR MOTOR (5 BAR) |
1 | |
| 5 |
0115-010099 | ROD CLIP | 2 |
| 6 |
41-28326 |
TIE ROD (6" OAL) TIE ROD (8" OAL) |
3 |
| 7 | 41-28300 | MOTOR ROD ADAPTER | 1 |
| 8 |
POGO FLUID SECTION (PTFE) POGO FLUID SECTION (UHMW) |
1 | |
| 9 | 0114-016243 | GROUND WIRE KIT | 1 |
| 10 | 41-28347 | UPPER GUARD | 1 |
| 11 | 41-28348 | LOWER GUARD | 1 |
| 12 | 41-166001 | SET SCREW | 3 |
NOTE: Please measure the overall length of item 6, Tie Rod, to ensure the correct length.
