Sagola V7 Mix Automatic Spray Gun

V7 Mix Automatic Spray Gun

Manufacturer: Sagola

Part #'s: PG3523010X

Description: The SAGOLA V7 Mix is a high production low pollution spray gun. Tungsten carbide product closure mechanism.

Applications:

• For tasks requiring a high opening and closure rate. Ideal to be used with robots and special machinery.
• For tasks where it is necessary to reduce mist and improve work conditions.
• Achieves a drastic reduction in product consumption.
• Spraying of clearcoats, UV paints, etc.

Features:

• Paint Flow Regulator- With integrated adjustable micrometer for a precise and homogenous paint regulation of all the guns in the line.
•  INOX- Automatic paint packing gland without gaskets that require handling. Nozzle and Needle. Made of stainless steel. Optional carbide.
• Detachable Paint-Head- Independent from the pneumatic zone, with four leak detection holes between them, covering all possible angles. 100% stainless steel option.
• Fan Regulator- This regulator allows us to adjust the size of the fan (of the atomization of air).
• Fan Control Regulator- This regulator controls the quantity and distribution of air between the lugs and central holes, allowing a perfect distribution of the spray pattern independently of the viscosity of the product.
• New Mooring and Guidance Systems- This new system allows removal and replacement of the spray gun from its workstation, keeping always with the same orientation. Wasted time spent adjusting spray guns at their workstations is eliminated completely.

Specifications:

Dimensions:	164 x 45 x 104 mm
Weight:	945 g / 2.083 lbs
Operation Inlet Connection:	4mm (0.157")
Air Inlet Connection:	8mm (0.314")
Product Inlet Connection:	BSP 1/2" H
Average Sound Pressure Level:	79db
Minimum Operational Pressure:	3.5bar (50.7psi)
Maximum Air Pressure:	30/150bar
Recommended Maximum Air Pressure:	2 bar (29psi)
Air Consumption:	150 L/min
Materials in contact with the product:	Stainless steel, tungsten carbide, Teflon, anodized aluminum, brass, nylon
Recommended application distance:	18 - 20cm (7 - 7.8")
Packing List:	Sagola V7 Mix Automatic Spray Guns supplied with Sagola V7 Mix Aircap & Air Assisted Airless Spray Tip (x1)

Parts:

Ref. No.	Part No.	Description
01	PT56418048	Sagola V7 Mix Aircap
26	PT56410210	Sagola V7 Mix Product Needle
39	PT81460XXX	Air Assisted Airless Tip
42/1	PT56418053	Spray Gun Product Filter - 100 Mesh, Pack of 10
42/2	PT56418054	Spray Gun Product Filter - 60 Mesh, Pack of 10
51	PT56418406	Sagola V7 Mix Product Needle Head & Nozzle Kit



Accessories:

• PT30010015 Air Assisted Airless Spray Tip Micro Filters, Pack of 10 (Use behind the spray tip to improve atomization quality)
• PT83660037 Air Assisted Airless Spray Tip 100 Layer Filter
  (Use behind the spray tip to improve atomization quality.  Made up of 100 horizontal layers to last longer than the standard micro filters)
• 56418589 Lubricant Grease (SAE 10), 100ml (3.38fl oz)
• 40000086 Spray Gun Cleaning Kit

Literature:

• Brochure
• Manual
• Line Drawing
